Atta Patthar Chakki

Roti Making Machine

ATTA PATTHAR CHAKKI

Product Specification

  • Production Capacity: 100 Kg/hr to 1000 Kg/hr (Model Dependent)
  • Grinding Mechanism: Traditional Patthar (Stone Grinding)
  • Stone Size: 12", 16", 18", 20" Stone Options Available
  • Automation Grade: Semi-Automatic / Manual
  • Power Consumption: 3 HP to 15 HP
  • Voltage: 220V / 415V, Single or Three Phase
  • Material of Construction: Mild Steel / Cast Iron / Stainless Steel
  • Operating Frequency: 50 Hz
  • Machine Size (LxWxH): 3ft x 2ft x 4ft (Approx.)
  • Flour Mesh Fineness: 90–95% Passing through 80 Mesh
  • Applications: Wheat, Multigrain, Maize, Bajra, Besan, and other grains
  • Control Panel: Manual / Optional Electric Starter
  • Warranty: 1 Year on Motor
  • Weight: 300–700 kg (Depending on stone size & model)
1
★★★★★

Enter Buying Requirements Details

* To get accurate quotes, please enter your name and mobile number

🇮🇳 +91

Product Important Parts

Part 1 Part 2

Product Functions

The Atta Patthar Chakki is a traditional stone-based flour grinding machine used to produce fresh and pure wheat flour. Ideal for small businesses, local mills, and commercial setups.
Natural stone grinding for high-nutrition flour, adjustable output mesh, rugged construction, low maintenance, and suitable for a wide range of grains like wheat, bajra, maize, and besan.
Plug in the machine, pour cleaned grains into the hopper, and collect finely ground flour at the output chute. Adjust settings as per mesh requirement.
Regularly clean the hopper and flour outlet. Check stone alignment and motor belt tension weekly. Lubricate bearings if necessary and avoid grain with moisture.
Do not operate with wet hands. Ensure proper earthing. Avoid inserting hands or tools into the hopper while in use. Always turn off power before cleaning or maintenance.
